COAXIALES

COMPABLOC 2000 geared motors with helical     A range of ten sizes : 26, 27, 28, 29.
gears are used to adapt the speed of the     Rated output torque : from 800 N.m to
electric motor to that of the driven machine.     16 000 N.m.
Their size is therefore determined by the     Power rating : from 0.37 to 90 kW.
motor power (P) expressed in kilowatts (kW)     Reduction ratios : from 1.25 to 160.
and the output rotation speed of the gear box (nS) in revolutions per minute (min-1).     From one to three reduction stages. High efficiency : 95 % to 98 %.
The main characteristic of the geared units     Reversible.
is the rated output torque (MnS) expressed     Silent operation.
in Newton-metres (N.m).


ORTOGONALES

ORTHOBLOC 2000 geared motors with helical     A range of seven sizes : 22, 23, 24, 25, 26,
bevel gears are used to adapt the speed of     27, 28.
the electric motor to that of the driven     Rated output torque : from 80 N.m to 10 000
machine.     N.m.
Their size is therefore determined by the     Power rating : from 0.18 to 75 kW.
motor power (P) expressed in kilowatts (kW)     Reduction ratios : from 5 to 125.
and the output rotation speed of the gear box (nS) in revolutions per minute (min-1).     Three reduction stages. High efficiency : 95 %.
The main characteristic of the speed     Reversible.
reducers is the rated output torque (MnS)     Silent operation.
expressed in Newton-metres (N.m).

PARALELOS

MANUBLOC 2000 geared motors with parallel     A range of six sizes : 21, 22, 23, 24, 25, 26.
gears are used to adapt the speed of the     Rated output torque : from 100 N.m to 4500
electric motor to that of the driven machine.     N.m.
Their size is therefore determined by the     Power rating : from 0.25 to 55 kW.
motor power (P) expressed in kilowatts (kW)     Reduction ratios : from 4.5 to 225.
and the output rotation speed of the gear     From two to three reduction stages.
box (nS) in revolutions per minute (min-1).     High efficiency : 95 % to 97 %.
The main characteristic of the speed     Reversible.
reducers is the rated output torque (MnS)     Silent operation.
expressed in Newton-metres (N.m).

PENDULARES

POULIBLOC 2000 geared motors with parallel     • A range of eight sizes for Pb 2000 series :
gears are used to adapt the speed of the     20, 21, 22, 23, 24, 25, 26, 27.
electric motor to that of the driven machine.     Rated output torque : from 100 N.m to
Their size is therefore determined by the     13 000 N.m.
motor power (P) expressed in kilowatts (kW)     Power rating : from 0.25 to 55 kW.
and the output rotation speed of the gear box (nS) in revolutions per minute (min-1).     Reduction ratios : from 3 to 25. From one to two reduction stages.
The main characteristic of the speed     High efficiency : 96 % to 98 %.
reducers is the rated output torque (MnS)     Reversible.
expressed in Newton-metres (N.m).    • A range of three sizes for Pb 3000 series :
30, 31, 32, lubricated with grease. Nominal output torque up to 820 N.m. • A range of three sizes for Pb 3000
    series : 31, 32, 33, lubricated with oil.
1. gearbox x belt-pulley. η η     Rated output torque up to 1100 N.m.

SINFÍN-CORONA

MULTIBLOC 2000 geared motors with worm     A range of six sizes : 31, 22, 23, 24,25, 26.
and wheel gears are used to adapt the     Rated output torque : from 20 N.m to
speed of the electric motor to that of the     1500 N.m.
driven machine.     Power rating : from 0.18 to 9 kW.
Their size is therefore determined by the     Reduction ratios : from 5.2 to 100.
motor power (P) expressed in kilowatts (kW)     Efficiency : 55 % to 88 %.
and the output rotation speed of the gear     Silent operation.
box (nS) in revolutions per minute (min-1).
The main characteristic of the speed
reducers is the rated output torque (MnS)
expressed in Newton-metres (N.m).

PLANETARIOS - EPICICLOIDALES

PLANIBLOC 2000 geared motors with planetary     A range of ten sizes : 21, 22, 23, 24,
gear train are used to adapt the speed of the     25, 26.
electric motor to that of the driven machine.     Rated output torque : from 100 N.m to
Their size is therefore determined by the     19 000 N.m.
motor power (P) expressed in kilowatts (kW)     Power rating : from 0.25 to 90 kW.
and the output rotation speed of the gearbox (nS) in revolutions per minute (min-1).     Reduction ratios : from 3.09 to 4 305. From one to four reduction stages.
The main characteristic of the gearbox is     High efficiency : 95 % per train.
the rated output torque (MnS) expressed in     Reversible.
Newton-metres (N.m).
